Logicwall®
Fibre cement based intertenancy wall system, for multi-residential projects
AFS Logicwall® panels are delivered with shop-drawn accuracy and featuring corresponding labels for easy installation. They are load bearing but lightweight enough to enable manual installation.
The panels provide reliably flat, true surfaces to help deliver high-quality finishes. Logicwall® is an ideal wall option for, intertenancy walls, corridor walls, lift and stair core walls for apartments, townhouses, and medium density housing.
A fast construction and engineering solution all in one
Each panel incorporates the structural functions of permanent framework, along with a hard-wearing finish, and deep beam transfer in one fast-to-erect solution.
Logicwall Demo
Watch our short 3min video on Logicwall® .
The intertenancy wall system with a 8-10 week lead time that keeps your projecting moving.
We work with your technical plans to swap out slow precast or blockwork for Logicwall®.
Logicwall Benefits
Panels delivered with shop drawn accuracy
Reduced Structural Footprint
Acoustic performance
Fire performance
AFS Logistics Service
Fast Construction Method
Logicwall Profiles
LW120
Single Reinforcement
LW150
Single Reinforcement
LW162
Single Reinforcement
LW200
Single Reinforcement
LW200D
Double Reinforcement
LW262
Double Reinforcement
Wall Thickness
120mm
150mm
162mm
200mm
200mm
262mm
Filled Wall Mass
290kg/m²
360kg/m²
394kg/m²
480kg/m²
480kg/m²
630kg/m²
Fire Resistance Level (FRL)
240/240/180++
240/240/180++
240/240/240+
240/240/240+
240/240/240+
240/240/240+
Acoustic Rating (STC)
50 STC
54 STC
55 STC
58 STC
58 STC
62 STC
The data shown above displays the AFS Logicwall profiles without strapping and lining.
For more options, refer to AFS acoustic report for further options or reach out to us.
One panel, full structural support
Engineers look to afs logicwall® for its ability to not only function as a wall and permanent formwork in one, but as a deep beam transfer panel. With this, an engineer can fulfil an architect’s plans of creating large open span spaces that require no column support, creating added valuable space in carparks, living areas and the like.
Minimal labour and handling
After being shop-drawn and custom-made to plan in the AFS factory, AFS logicwall®’s Intertenancy wall lightweight nature means that upon delivery no tower cranes are required for lifting. And no other types of crane are required – individual panels can be erected by hand, after which they are core-filled with AFS’s specified easy-flow concrete mix.
Significant Waste Reduction On Site
AFS Logicwall® panels are made to measure and delivered to your site ready for installation. The result is a massive reduction in onsite preparatory work, which in turn drastically reduces expenses for skips and waste removal.
Hard-wearing Concrete feel finish
Eliminate the added expense of constructing stud and plasterboard finishing. AFS Logicwall® also doubles as an excellent hard-wearing substrate for applied finishes such as skim coating, acrylic render and paint.
Logicwall Design Guide
Architects, engineers and builders find the Logicwall® Design Guide full of the technical information they need for using Logicwall® in their projects:
With chapters covering:
- fire & acoustic certifications
- installation
- architectural detailing
- applications
- and more!
View Logicwall Resources
Access design guides, product brochures, compliance and certification documents, videos, and FAQs to get started using AFS Logicwall for your building projects.
Advice and answers from experienced staff
